VB552 Aten VGA Over CAT 5 Repeater with Audio

£159.00 inc VAT

Aten VB552 VGA & Audio over CAT5 repeater extends the transmission range an extra 150m with  high-quality video – up to 1920×1200@60Hz at 30m, 1600×1200@60Hz at 150m, 1280×1024@60Hz at 200m. Video gain and compensation are adjustable via OSD and IR remote control for screen on/off and video adjustment at remote site. It is Audio andSerial enabled.

Data Sheet

Manual

Description

The VB552 VGA Over Cat 5 Repeater +Audio is an audio/video signal extension device which is compatible with ATEN Cat 5 Audio/Video splitters. The VB552 extends the audio/video transmission range an extra 150m over Cat 5e (or higher) cables. The use of an additional repeater means the audio/video signals can be transmitted over even longer distances, up to 450m.

Furthermore, for longer distance installations where video signals may degrade, the VB552 has adjustable video gain and compensation controls to provide the sharpest video quality possible. An IR remote control also provides picture control at the remote site.
Rack-mountable, with two RS-232 channels on the unit for selection, and support for high video resolutions, the VB552 is the perfect solution to extend the range of your A/V and serial transmissions in any installation environment requiring VESA FDMI mount standards.

  • Uses Cat 5e cable to extend audio/video signal
  • Extends the transmission range an extra 150m
  • High-quality video – up to 1920×1200@60Hz at 30m, 1600×1200@60Hz at 150m, 1280×1024@60Hz at 200m
  • Audio and serial enabled
  • Two gain control modes for sharpest picture quality
  • Video gain and compensation adjustable via OSD
  • IR receiver for quick and easy video quality adjustment
  • IR remote control for screen on/off and video adjustment at remote site
  • Provide a RS-232 channel for selection*
  • Follows VESA FDMI mount standard
  • Supports DDC for the local monitor
  • Supports VGA, SVGA, XGA, SXGA, UXGA and multisync monitors
  • For use in combination with VS1504/VS1508 Audio/ Video splitter
    * Only one RS-232 channel can be selected at a time
Video Output Interface 2 x HDB-15 Female (Blue)
Impedance 75 Ώ
Max Distance 1.8 m
Video Max Bandwidth 300 MHz
Max Resolutions / Distance Up to 1920 x 1200@60Hz@30m;
1600 x 1200@60Hz@150m
Audio Output 2 x Mini Stereo Jack Female (Green)
Control RS-232 Connector: 2 x DB-9 Male (Black)
Power Connector: 1 x DC Jack (Black)
Consumption: 5.3 VDC, 4.77W
Environment Operating Temp. 0-50°C
Storage Temp. -20 – 60°C
Humidity 0-80% RH, Non-Condensing
Physical
Properties
Housing Metal
Weight 0.35 kg
Dimensions
(L x W x H)
13.90 x 8.80 x 2.86 cm
  • 1x VB552 VGA Over Cat 5 Repeater + Audio
  • 1x Power Adapter
  • 1x Infrared Remote Control Handset
  • 1x Infrared Receiver
  • 1x IR Receiver Holder
  • 1x Mounting Kit
  • 1x User Instructions
