4K-810 Smart-e 100m 4K HDMI HDBaseT 3D Fully HDCP Extender Pair with IR & RS232

£425.00 inc VAT

Smart-e 4K-810 100m HDBaseT extender pair for HDMI, Infrared, 100baseT Ethernet and RS232. Resolutions 4k,2k, 1080p@60Hz, 3D fully HDCP compliant. It distributes signals over a single 70m CAT 5-8 cable with wide bandwidth IR transmission and Ethernet and RS232 pass-through. It features dual port Ethernet switch and it is compatible with Smart TV’s.

Data Sheet

Manual

Description

The 4K-800 is a transmitter and receiver pair designed to extend HDMI, DVI or DisplayPort, together with and bidirectional IR signals over a single twisted pair CAT 5e-8 cable. The units use HDbaseT technology to extend 12 bit Deep Colour 3D, 4K and 2K resolutions together with 1080p @60Hz.

Infra-Red pass-through is available via an internal IR receiver in the 4K-RX800 and external IR emitter (SM-LED) connecting to the 4K-TX800. The IR is extended through the same CAT 5e-8 cable together up to 100m. Each box has fixing holes to facilitate ease of installation and multiple units can fit side by side on a 1U 19” rack shelf.

4K-810 Features:

  • HDMI, DVI & Display Port
  • HDMI, Deep Colour, 3D, 4K & 2K resolutions
  • 3D compatible
  • Distributes signals over a single 70m CAT 5-8 cable
  • HDCP compliant
  • Infra-red signal passthrough
  • Wide bandwidth IR transmission
  • Locking DC connector
  • Supports resolutions up to 4K
  • Units can be powered via USB (5v)
  • RS232 pass-through
  • Ethernet pass-through
  • Dual port Ethernet switch
  • Compatible with Smart TV’s
  • High ground loop immunity
  • HDBaseT
