SLX-214 Smart-e 300m CATx for Dual UXGA, RS232, IR & Audio Extender with Inline Power

£839.00 inc VAT

Smart-e SLX-214 up to 300m Dual UXGA , RS232, IR and audio over CATx extender features multi-format video: RGBHV, CVBS, YUV, YPrPb, Y/C, RGsB and supports up to 1600×1200 UXGA inputs.  The extender supports HD component  HD 1080p YPrPb inputs, up to 62ns skew compensation, transparent RS232 passthrough and it is HDTV 720p and 1080i.

Data Sheet



Long Range Transmitter and Receiver pair for UXGA, YUV, Y/C and CVBS and Stereo Audio with RS232 or Infra-Red passthrough for control with various discrete connectors.

The SLX–214 will extend UXGA/HighDef YUV, Y/C, CVBS and stereo audio over 300m of CAT 5-8 cabling. With the ability to also transfer RS232 or Infra-Red control transparently.

  • Multi-format video: RGBHV, CVBS, YPrPb, Y/C and RGsB
  • Single CAT 5-8 for video, audio, control & power
  • Supports up to 1600×1200 UXGA
  • Transparent RS232 pass-through
  • Supports HD 1080p YPrPb inputs
  • Supplies remote power to receivers
  • HDTV 720p, 1080i compatible
  • Line level Stereo Audio
  • Wide bandwidth IR transmission
  • Uses easy to install, inexpensive CAT 5-8
  • Discrete connectors
  • Up to 62ns of skew compensation
  • Separate contrast control
  • High ground loop immunity
  • ‘Plug and Play’ connection
