N117-UIP1602e Austin Hughes 17″ Console Drawer One IP with 16 Port CATx KVM Switch

£2,154.00 inc VAT

The N117-UIP1602e 1U Rackmount LCD Monitor and Keyboard Drawer supports 16 ports in a slim 1U rackmount drawer. Dual Console (Local and IP) KVM and includes keyboard and touchpad mouse and a 17″ 1280 x 1024 resolution LCD monitor.The N117-UIP1602e 1U Rackmount LCD Monitor and Keyboard Drawer is a cost effective way to monitor and manage multiple servers.




The N117-UIP1602e feature a 1U Rack mountable LCD, Keyboard as well as a built in low profile 16 port Cat5 KVM switch. Designed for single or one man installation, the 1U devices are available in either 17 or 19 inch screen version. The full keyboard with numerical pad is supplied with either touchpad or trackball. Enhanced user benefits compared with previous KVM switch platforms are increased density, up to 40m between switch and server, enhanced cable management and multi-platform capabilities. Using a PS/2 or USB dongle at the server end of the installation provides a cost effective method of matching the server configuration, allowing legacy servers to be migrated to a USB interface without replacing switch hardware. Switches can be cascaded together up to 8 levels allowing 256 connections with the use of the CBC-6 cable. The two-user IP switch means a second user can work securely via a remote keyboard, monitor and mouse using 128 bit secure IP access across the web. The plug and play technology provides seamless, secure access over IP via a web browser, allowing control down to bios level; no software is installed on the servers or remote PCs.

N117-UIP1602e Features:

  • 104 key keyboard with touchpad mouse
  • Side rails with fixed positions to prevent drawer movement when typing
  • Combo (USB, PS/2 and VGA in one cable) server connections with Cat6 console connection (enabling remote connections up to 1,000 feet)
  • 17″ LCD monitor with:
    • 1280 x 1024 resolution
    • 300 cd/m2 brightness
    • 160 degree viewing angle (horizontal and vertical)
    • Support for 16.7 million colors
    • 1 millisecond response time
  • Compatible with PC, Sun, IBM, HP, Dell and other servers
  • “One man” installation – just slides in!
  • 2 year warranty
Size U 1u
Internal Height 1.75″h
Internal Width 17.4″w
Internal Depth 25.6″d
Number of Ports 16
Connector Type/Style Cat6
Mouse Type Touchpad
Resolution 1280 x 1024

2 year
