VS481A Aten 4-Port HDMI Switch

£81.18 inc VAT

Aten VS481A 4-port HDMI switch allows convenient switching between 4 digital devices such as DVD players, Satelite receivers, Digital Camcorder. The VS481A allows you to select the desired input source via a remote control unit and pushbuttons located on the switch. It features superior video quality – HDTV resolutions of 480p, 720p, 1080i, 1080p (1920×1080); VGA, SVGA, SXGA, UXGA (1600×1200) and WUXGA(1920×1200), 3D, Dolby True HD and DTS HD Master Audio, long distance transmission – up to 15m (24 AWG), DDC & HDCP 1.1 compatible, and a built-in bi-directional RS-232 serial remote port for high-end system control.

Data Sheet

vs481a-rs-232-s_2012-10-09.pdf (447.53 KB

vs481a-w_2015-08-31.pdf (419.93 KB)

VS481A-IR Command-s_2013-08-30.pdf (25.65 KB)



Description

The VS481A 4 Port HDMI Switch allows you to quickly and easily share your HDMI display device with 4 HDMI input sources. The VS481A allows convenient switching between digital devices such as DVD players, Satelite receivers, Digital Camcorder. The VS481A allows you to select the desired input source via a remote control unit and pushbuttons located on the switch.

  • Allows up to four HDMI A/V source to be connected to one HDMI display
  • Toggle between A/V sources using remote control or front panel pushbuttons
  • Superior video quality – HDTV resolutions of 480p, 720p, 1080i, 1080p (1920×1080); VGA, SVGA, SXGA, UXGA (1600×1200) and WUXGA(1920×1200)
  • HDMI (3D, Deep Color)
  • Supports Dolby True HD and DTS HD Master Audio
  • Up to 60 Hz refresh rate
  • Long distance transmission – up to 15m (24 AWG)
  • Built-in bi-directional RS-232 serial remote port for high-end system control
  • Power On Detection – if one of the HDMI source devices is powered off, the VS481A will automatically switch to the next powered on device
  • Plug-and-play – no software installation required
  • DDC Compatible
  • HDCP 1.1 compliant
  • Signaling rates up to 2.25 Gbits in support of 1080p display
  • All-metal casing
  • LED indication of video source devices
  • Easy and affordable way to add four HDMI inputs to your home theater system* Note: The VS481A AP and GUI operation instructions can be downloaded from the ATEN website (www.aten.com)
Video Input
Interface 4 x HDMI Type A Female (Black)
Impedance 100 Ώ
Max. Distance 1.8 m
Video Output
Interface 1 x HDMI Type A Female (Black)
Impedance 100 Ώ
Video
Max. Data Rate 6.75 Gbps (2.25 Gbps Per Lane)
Max. Pixel Clock 225 MHz
Compliance HDMI (3D, Deep Color)

HDCP Compatible

Consumer Electronics Control (CEC)

Max. Resolution Up to 1080p
Max. Distance Up to 15 m
Audio
Input 4 x HDMI Type A Female (Black)
Output 1 x HDMI Type A Female (Black)
Control
RS-232 Connector: 1 x DB-9 Female (Black)
Baud Rate and Protocol:
Baud Rate: 19200, Data Bits: 8, Stop Bits:1, Parity: No, Flow Control: No
Power
Connectors 1 x DC Jack
Consumption 5 VDC, 2.4W
Environmental
Operating Temperature 0 – 50°C
Storage Temperature -20 – 60°C
Humidity 0 – 80% RH, Non-Condensing
Physical Properties
Housing Metal
Weight 0.47 kg
Dimensions (L x W x H) 20.00 x 8.27 x 2.50 cm
  • 1x HDMI Switch
  • 1x Standard HDMI cable (1.8m)
  • 1x IR Remote Control Unit
  • 1x Power Adapter
  • 1x User Instructions
