HFX-KM SmartAVI HDMI & USB 2.0 Extender Via Fibre

£1,975.00 inc VAT

SmartAVI  HFX-KM is a Single Head HDMI 2.0 (3840 x 2160), USB 2.0, USB keyboard-mouse, sending signals up to 10 km (6.2 miles) away over a single conventional and inexpensive single fibre cable. This new technology is superior to older HDMI extenders that require a special single fibre shielded cable to go a short distance. NEW

Brochure

Description

The SmartAVI HFX-KM is a Single Head HDMI 2.0 (3840 x 2160), USB keyboard-mouse and stereo audio extender, sending signals up to 10 km (6.2 miles) away over a single conventional and inexpensive single fiber cable. This new technology is superior to older HDMI extenders that require a special single fiber shielded cable to go a short distance.

The HFX-KM is the leading extender on the market to feature 3840 x 2160 @ 60 Hz, USB and full KVM extension and emulation on one cohesive system and is optimized for UHD 4K@60Hz monitors with crystal-clear picture; excellent for detail driven work.

The HFX-KM extends keyboard-mouse signals for remote workflow management and offers uninterrupted emulation from the user’s transmitter unit. This uninterrupted emulation prevents accidental disconnection or deactivation issues during mission critical operations. The HFX-KM‘s unparalleled KVM extension technology makes it the perfect solution for extending servers in applications ranging from data processing to interactive conferencing.

  • USB Keyboard and Mouse extension
  • External power adapter for transmitter and receiver unit
  • Supports Stereo Sound
  • Compatible with Windows, Mac and Linux Operating Systems
  • RS232 Serial Extension
  • SmartAVI Ultra Low Latency
VIDEO
Format HDMI2.0
Video Resolution Resolution: high definition 3840 x 2160
Color Depth: 24-bit color depth
Latency: less than 1 ms
Video Bandwidth Single-link 340 MHz (10.2 Gbps)
Input Interface (1) HDMI 19-pins (female)
(1) HDMI 19-pins (female) (local)
Output Interface (1) HDMI 19-pins (female)
(1) HDMI 19-pins (female) (local)
Max Output Distance Up to 20 f
Equalization Automatic
Input TMDS Signal 1.2 Volts [peak-to-peak]
Input DDC Signal 5 Volts [peak-to-peak, TTL]
Data Rate 1.65 Gbps per color
AUDIO
Format Stereo
Input Interface 3.5 mm Jack Socket (female)
Output Interface 3.5 mm Jack Socket (female)
USB
Input Interface (TX) (1) USB Type B
Output Interface (RX) (2) USB 1.1 Type A for KM Devices
Keyboard and mouse Keyboard and mouse emulation
SERIAL
Input Interface (TX) (1) RS232 Serial, 3-pin pheonix connector
Output Interface (RX) (1) RS232 Serial, 3-pin pheonix connector
SYSTEM
Extension Type Fiber (LC-LC Single
Cable Requirements Single Fiber
Maximum Length Single mode: 10 km (6.2 miles)
Multi mode: 500 m (1640 feet)
OTHER
Power 100-240 VAC/ 5VDC @ 3A/15W
Dimensions 7.8” W x 1.15” H x 3.65” D
Weight 1 lb (.5 lbs per unit)
Approvals UL, CE, ROHS Compliant
Operating Temperature +32 to +104°F (0 to +40°C)
Storage Temperature -4 to 140°F (-20 to +60°C)
Operating Humidity 20% to 80% (non condensing)
Storage Humidity Up to 95% (No Condensation)
Compliance EMC FCC (Class A), CE (Class A), ICES-003
Environmental Compliance RoHS2 (CE)
Support Warranty 1-year
  • Digital Signage
  • Security
  • PC Networking
  • Conference Center Systems
  • Point of Sale
  • Camera Surveillance
  • Video Phone
  • Control Room Systems
  • Recording Studio
  • PC KVM Extension

HFX-KM-S HDMI, USB, Audio via Single Fiber Extender. Includes: [HFX-KM-TX-S, HFX-KM-RX-S, 2 X (PS5VD3A)]
HFX-KM-TX-S HDMI, USB, Audio via Single Fiber Transmitter. Includes: [HFX-KM-TX-S, PS5VD3A-WLLMNT]
HFX-KM-RX-S HDMI,USB, Audio via Single Fiber Receiver. Includes: [HFX-KM-RX-S, PS5VD3A-WLLMNT]
