Aten CS1794 4 port USB and HDMI KVMP switch with Video DynaSync technology and high-definition sound. It is supplied with all necessary KVM cables to connect 4 computers.
With its unique design and innovative features, the CubiQ™ CS1794 USB 2.0 HDMI KVMP™ Switch provides both style and functionality for today’s multimedia SOHO environment. Combining a 4-port switch with a 2-port USB 2.0 hub, the CS1794 provides seamless HDMI signal switching between 4 PCs or other HDMI-enabled devices, such as gaming consoles, and allows users to share USB peripherals from a single console.
The CS1794 provides enhanced independent switching via front panel pushbuttons and keyboard hotkeys, and features Video DynaSync™ technology to ensure that HDMI display resolution is always optimized. With integrated digital audio, the CS1794 also allows users to experience high-definition sound, such as Dolby True HD and DTS HD Master Audio.
Ideal for multimedia applications in the home or office, the CubiQ™ CS1794 offers the ultimate in space-saving, streamlined KVM technology for the desktop.
|Port Selection||Front Panel Pushbuttons; Hotkeys|
|Connectors||Console Ports||Keyboard||1 x USB Type A Female
(Black; rear panel)
|Video||1 x HDMI Type A Female (Black)|
|Mouse||1 x USB Type A Female
(Black; rear panel)
|Speaker||2 x Mini Stereo Jack Female (Green; 1 x front, 1 x rear)|
|Mic.||2 x Mini Stereo Jack Female
(Pink; 1 x front, 1 x rear)
|KVM Ports||Keyboard / Mouse||4 x USB Type B Female (White)|
|Video||4 x HDMI Type A Female (Black)|
|Speaker||4 x Mini Stereo Jack Female (Green)|
|Mic.||4 x Mini Stereo Jack Female (Pink)|
|F/W Upgrade||1 x 4-conductor 3.5mm Jack (Black)|
|Power||1 x DC Jack|
|USB 2.0 Hub||2 x USB Type A Female
(White; 1 x front panel; 1 x rear panel)
|Switches||Selected||5 x Pushbutton|
|Video||1080p (HDTV) / 1920 x 1200 (DVI)|
|Scan Interval||1-99 secs. (Default: 5 secs)|
|Power Consumption||DC 5.3 V, 4.8 W|
|Humidity||0-80% RH, Non-condensing|
|Physical Properties||Housing||Metal, Plastic|
(L x W x H)
