Adder ALDV104K 2×4 up to 50m CATx AV HDMI splitter /matrix switch Kit uses an uncompressed video system where every frame is sent without loss with resolutions up to 1920 x 1200@60Hz (WUXGA) including 1080p, 720p and 480p resolutions. With two inputs, the system is suited to extending and splitting dual head systems. The switch has intelligent EDID management allowing the true characteristics of the monitor to be passed back to the computer. The DV104T is delivered in a zero config state so you can plug and play. There is no need for additinal drivers or software.
ADDERLink DV104K is a high performance digital video extender and splitter that enables you to locate your critical play out hardware in a secure and temperature controlled environment away from the display point environment whilst maintaining the same user experience.
The ALDV104K uses an uncompressed video system where every frame is sent without loss with resolutions up to 1920 x 1200@60Hz (WUXGA) including 1080p, 720p and 480p resolutions.
With the ALDV104K, video, audio and power all pass along a single CATx cable, providing up to 50m of extension. Distance can be dependent upon CATx cable types and the number of connection breaks for patch panels and wall plates. See overleaf for details.
