SY-HDBT-231-100-SET S Y Electonics Dual HDMI to 3 x 1 HDBT 100m Transmitter Extender Set

£1,595.00 inc VAT

S Y Electronics SY-HDBT-231-100-SET dual 4K UHD HDMI inputs to 3 x 100m HDMI plus 1 x HDMI outputs. It features de-embeded audio with Rs232, IR control, EDID management and provide Power Over Cable (PoC) to the receivers. he HDBaseT outputs can respectively broadcast up to 70m/100m @ 1080p or 40m/70m @ 4K 30Hz using cat6a cable and it is HDCP2.2 compatible. The SY-HDBT-231-100-SET includes 3 x HDBaseT Receivers

Manual

Description

The HDBT-231-70/100 is a dual HDMI to 3x HDBaseT Transmitter with a local HDMI loop out – Single Zone DA.

The HDBT-231-70 and HDBT-231-100 provide a selection from one of two HDMI input sources and distributes that selection to three HDBaseT outputs and a local HDMI output.

The HDBaseT outputs can respectively broadcast up to 70m/100m @ 1080p or 40m/70m @ 4K 30Hz using cat6a cable (using HDBT-70SE-R or HDBT-100-SLIM-R receivers).

SY-HDBT-231-70 Transmitter /Extender

  • 2 4K UHD HDMI 2.0 Inputs
  • 3 HDBaseT Outputs + 1 HDMI Loop Output
  • Bi-directional pass-through RS232 and IR
  • RS232 Control
  • EDID Management
  • Provide Power over Cable (PoC) to the receivers
  • Compatible with HDBT Slim Receivers
  • Cascade up to 6 units
  • HDCP2.2 compatible
  • 48V DC Power
  • 1U rack mount chassis
  • Data rate 10.2 Gbps

1x HDBT-231-100

3 x HDBaseT Receivers
1x Set removable Rack Ears mounting brackets
3x Phoenix connectors
1x PSU
1 User Manual
